*1 Based on the cubic volume of color LED/laser printers commercially available as of September, 2022.
Media Flexibility
Easily print on a wide variety of media
Eye-catching color labels
Produce high-quality color results that catch the eyes of customers
Produce high-quality color results that catch the eyes of customers
Create new profits by colorizing the black-and-white thermal printing environment
Various interface support
USB and wired LAN as well as optional wireless LAN are provided. Print without restrictions on the environment
| Model | Order number | Price (RRP) | Features |
|---|---|---|---|
| Pro330S | 47097011 |
Toner technology delivers high print quality
No need for expensive inkjet media. The toner method is excellent water and alcohol resistance.
CMY Toner Cartridge
With just one toner, you can keep inventory and speed up production, simplifying your warehouse. The three-color all-in-one toner can be replaced simply and the unit can be used quickly with no delay in replacement.
Eye-catching print results – catch your customers’ eyes and attract your target audience
Ideal for customers and print shops, the Pro330S color label printer is designed to print high-quality color labels that are higher than the conventional black-only thermal printing environment. Print with minimal waste and save valuable time and budget.
- Replace the thermal printing environment where only black-and-white printing was possible with high-quality color
- Expressing and highlighting the unique characteristics of the product’s content
| Printing Method | Digital 3 LED Full-color Electrophotographic Printing Method |
|---|---|
| Media Type | Plain Paper, Plain Paper Label, Glossy Paper Label, Film Label |
| Media Width | 25 – 86mm |
| Media Thickness *1 | 0.08 – 0.25mm |
| Media Length | 53 – 551mm |
| Media Detection | None Black Mark (bottom) Black Mark (top) Hole Gap |
| Media Form *2 *3 | Roll-fed Fan-Fold Cut Sheet |
| Roll Outer Diameter | Max. Ф203.2mm (Ф8″) |
| Core Inner Diameter | Min. Ф50.8mm |
| Roll Wind Direction | Face-out |
| Total Media Weight | Max. 2.4kg |
| Force of Tugging at Media of Feed Roller | 10N or more |
| Print Width | Max. 80mm |
| Minimum Print Margin | Top:2.03mm Bottom:2.03mm Right:2.03mm Left:2.03mm *** The minimum margin (top, bottom, left, right) that the printer driver can set is 2.1mm. |
| Print Position Accuracy | Vertical : ±1.0mm Horizontal : ±1.0mm |
| Cut Accuracy *4 *5 | Media length 216mm or under : ±1.5mm Media length over than 216mm: ±0.7% Squareness accuracy: 1/100 or under Straightness accuracy: 1.0mm or under |
| Cuttable Media Length | 53 – 551mm |
| Print Resolution | 1200 x 1200 dpi 600 x 600 dpi Physical dot pitch: 1200 dpi |
| Print Speed *6 | Max. 152.4mm/s (6ips) |
| Warm-up Time | Approx. 23.0 seconds from power-on Approx. 28.0 seconds from power save |
| Time To First Print | Approx. 5 seconds (Cold start) Approx. 4 seconds (Pre heat) |
| Interface | USB 2.0 (High Speed), 100BASE-TX/10BASE-T, (Optional) Wireless LAN (IEEE802.11a/b/g/n) |
| Protocol | TCP/IP |
| Printer Language | PCL 6 (XL) emulation, PCL 5c emulation |
| Supported OS | Windows 10, Windows 10 x64, Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012 |
| Memory (Std./Max.) | 512 MB / 512 MB |
| Font | PCL emulation 27 scalable fonts, 4 bitmap fonts |
| Media Sensors | Position adjustable Transmission Hole, Gap, Notch Sensor Position adjustable Reflective Black Mark (bottom) Sensor Position adjustable Reflective Black Mark (top) Sensor Paper End Sensor |
| Auto Cutter | Rotary blade Full cut |
| Presenter Mode | Optional |
| Buzzer | Standard |
| Dimensions(WxDxH) | 198 x 380 x 195 mm |
| Weight(includes supplies) | Approx. 9.5 kg |
| Operating Environment | Operating: 10 – 32 °C, 20 – 80 %RH No condensation |
| Power Source *7 | Single phase 220 – 240 VAC ±10%, 50/60 Hz ±2% |
| Power Consumption | Operating: Max. 650W / Ave. 250W Idle: 10W Power Save: < 5.0W Deep Sleep: < 1.0W Auto-Off: < 0.5W |
| Noise Level | Operating: Approx. 55 dBA Idle: < 37 dBA |
| Safety& Environment Regulation | RCM Mark, RCM Mark |
| Unit Life *8 | 5 Years or 120 km |
| Cutter Life | 1.0 million cuts |
| Duty Cycle | Recommended: 1,500 pages/month Maximum: 12,000 pages/month |
| In the Box | DVD-ROM, Power cable, Guide Rib x 4 |
Footnotes;
*1 For single paper (cut paper), it will be 0.06 to 0.25 mm.
*2 Do not use seam paper.
*3 Do not use roll paper that is taped or glued to the roll core
*4 Squareness and straightness do not include 4.2 mm from the edge of the paper.
*5 If the position of the black mark is 33.2 mm or more from the tip of the paper (previous cut position), it is recommended to cut at the center of the black mark.
*6 Printing speed varies depending on paper size, type, and thickness
*7 Operation is not guaranteed when using a UPS (Uninterruptible Power Supply) or an inverter.
*8 Equipment life depends on customer usage
